Diameter: NPS 2ˇ48

Pressure: Class150ˇClass900

Design and manufacturing: API 608ˇAPI 6D

Face-to-face dimensions: ASME B16.10ˇAPI 6D

Pressure test: API 598ˇAPI 6D

Transmission mode: Manual, worm and worm gear transmission, pneumatic, electric

Nominal diameter(in): NPS 2ˇ48

Nominal pressure(Class): Class150ˇClass900

Design and manufacturing: API 608ˇAPI 6D

Face-to-face dimensions: ASME B16.10ˇAPI 6D

Pressure test: API 598ˇAPI 6D

Transmission mode: Manual, worm and worm gear transmission, pneumatic, electric

Nominal diameter(in): NPS 2ˇ48

Nominal pressure(Class): Class150ˇClass900

Design and manufacturing: API 608ˇAPI 6D

Face-to-face dimensions: ASME B16.10ˇAPI 6D

Pressure test: API 598ˇAPI 6D

Transmission mode: Manual, worm and worm gear transmission, pneumatic, electric

Nominal diameter(in): NPS 2ˇ16

Nominal pressure(Class): Class150ˇClass2500

Design and manufacturing: API 608ˇAPI 6D

Face-to-face dimensions: ASME B16.10ˇAPI 6D

Pressure test: API 598ˇAPI 6D

Transmission mode: Manual, worm and worm gear transmission, pneumatic, electric

Nominal diameter(in): NPS 6ˇ48

Nominal pressure(Class): Class150ˇClass1500

Design and manufacturing: API 608ˇAPI 6D

Face-to-face dimensions: ASME B16.10ˇAPI 6DˇJIS B2002

Pressure test: API 598ˇAPI 6D

Transmission mode: Manual, worm and worm gear transmission, pneumatic, electric

Nominal diameter(in): NPS 2ˇ36

Nominal pressure(Class): Class150ˇClass900

Design and manufacturing: API 608ˇAPI 6D

Face-to-face dimensions: ASME B16.10ˇAPI 6D

Pressure test: API 598ˇAPI 6D

Transmission mode: Manual, worm and worm gear transmission, pneumatic, electric

Nominal diameter(in): NPS 2ˇ36

Nominal pressure(Class): Class150ˇClass900

Design and manufacturing: API 608ˇAPI 6D

Face-to-face dimensions: ASME B16.10ˇAPI 6D

Pressure test: API 598ˇAPI 6D

Transmission mode: Manual, worm and worm gear transmission, pneumatic, electric

Size: DN50~DN1200, 2 inch -48inch;

Rating pressure: PN16~PN150, ANSI 150lb ~ 900lb;

Body Materials: Carbon Steel, Low-temperature Carbon steel, Stainless Steel, Forged Duplex Stainless Steel;

Trim: A105+ENP, A350 LF2+ENP, Stainless steel(SS304, SS316 etc.), etc.

Operation: Lever Or Wrench Operated, Gearbox etc.

Available Temperature range：-196℃~-29℃；

Size: DN50~DN1200, 2 inch-24inch;

Rating pressure: PN16~PN150,ANSI 150lb ~ 600lb;

Body Materials: Low-temperature Carbon steel, AusteniticStainless Steel;

Trim: SS304, SS316 etc.

Operation: Lever Or Wrench Operated, Gearbox etc.

Available Temperature range：-196℃~-29℃；

Size: DN50~DN600, 2 inch-24inch;

Rating pressure: PN16~PN100,ANSI 150lb ~ 600lb;

Body Materials: Low-temperature Carbon steel, AusteniticStainless Steel;

Trim: A350 LF2+ENP, Stainless steel(SS304, SS316 etc.), etc.

Operation: Lever Or Wrench Operated, Gearbox etc.

Size: DN50~DN600, 2 inch-24inch;

Rating pressure: PN16~PN250,ANSI 150lb ~ 1500lb;

Body Materials: Carbon Steel,Low-temperature Carbon steel,Stainless Steel, Forged DuplexStainlessSteel;

Trim: A105+ENP, A350 LF2+ENP, Stainless steel(SS304, SS316 etc.), etc.

Operation: Lever Or Wrench Operated, Gearbox etc.

Size: DN50~DN1200, 2 inch-48inch;

Rating pressure: PN16~PN420,ANSI 150lb ~ 2500lb;

Body Materials: Carbon Steel,Low-temperature Carbon steel,Stainless Steel, Forged DuplexStainlessSteel;

Trim: A105+ENP, A350 LF2+ENP, Stainless steel(SS304, SS316 etc.), etc.

Operation: Lever Or Wrench Operated, Gearbox etc.

Size: DN50~DN1200, 2 inch-48inch;

Rating pressure: PN16~PN250,ANSI 150lb ~ 1500lb;

Body Materials: Carbon Steel,Low-temperature Carbon steel,Stainless Steel, Forged DuplexStainlessSteel;

Trim: A105+ENP, A350 LF2+ENP, Stainless steel(SS304, SS316 etc.), etc.

Operation: Lever Or Wrench Operated, Gearbox etc.

Size: DN50~DN1200, 2 inch-36inch;

Rating pressure: PN16~PN250,ANSI 150lb ~ 1500lb;

Body Materials: Carbon Steel,Low-temperature Carbon steel,Stainless Steel, Forged DuplexStainlessSteel;

Trim: A105+ENP, A350 LF2+ENP, Stainless steel(SS304, SS316 etc.), etc.

Operation: Lever Or Wrench Operated, Gearbox etc.
